Build Volume250 × 220 × 270 mm | 9.8 × 8.6 × 10.6 in
Filament diameter1.75 mm
Layer height0.05-0.30 mm
Printer dimensions22.5 kg, 415 × 444 × 555 mm; 16.3 × 17.5 × 21.8 in (X×Y×Z)
MainboardCustom 32-bit xBuddy electronics with STM32
Stepper DriversTrinamic 2130
Stepper motorsPrecise 0.9° X,Y stepper motors (prevents VFA)
ExtruderNextruder, Direct Drive, E3D V6 compatible (with adapter)
Extruder electronicsCustom breakout board for connecting fans, thermistors and other parts
Filament pathAluminum heatsink, all-metal hotend
Drive systemNextruder Planetary Gear System, 10:1 gearbox ratio
Cooling fanHigh-performance turbine, 360° cooling system
NozzleHigh-flow Prusa Nozzle brass CHT - 0.4 mm
Max nozzle temperature290 °C / 554 °F
Max heatbed temperature120 °C / 248 °F
Max chamber temperature55 °C / 131 °F
LCD screen3.5″ graphic 65k color screen
Touch controlYes
Firmware update interfaceUSB drive, Prusa Connect, Prusa Mobile App
Prusa Connect supportYes
Quick-Swap nozzle systemYes
Internal cameraOptional, in-chamber solution
Multi-Material SupportYes, MMU3 (5 filaments) and INDX (up to 8 filaments)
HEPA filtrationOptional addon
ConnectivityEthernet, Wi-Fi (NFC receiver, optional Wi-Fi module)
Filament SensorYes (2 sensors)
Loadcell sensorYes
Print surfaceMagnetic heatbed with removable PEI spring steel sheets
First layer calibrationFully automatic (Load Cell sensor)
Input shaperYes
Supported materialsPLA, PETG, Flex, PVA, PC, PP, CPE, PVB (Advanced: ABS, ASA, HIPS, PA)
PSU240W with Power Panic HW
Power consumptionPLA: 90W / ABS: 110W
